Description
Included
-
Nose type – Sprocket nose
-
Spikes – Mounted
-
Chain type – SP33G
-
Bar length (inch) – 16 in
| Engine |
16″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑36
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑02
|
16″ SN .325″ 1,5 mm S35G
SKU: 967 69 06‑16
|
18″ SN .325″ 1,5 mm S35G
SKU: 967 69 06‑18
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑28
|
18″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑38
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑40
|
| Chain speed at max power | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts |
|---|---|---|---|---|---|---|---|
| Cylinder displacement | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ |
|
Output shaft power1
|
3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp |
| Torque, max. | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm |
| Torque, max. at rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm |
| Clutch engagement speed (±120) | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
| Electrode gap | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
| Idling speed | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
| Ignition module air gap | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
| Maximum power speed | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm |
| Oil pump type | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
| Spark Plug | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
| Equipment | |||||||
| Recommended bar length, min | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
| Pitch | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ |
| Recommended bar length, max | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in |
| Chain type | SP33G | SP33G | S35G | S35G | SP33G | SP33G | SP33G |
| Bar length | 40 cm | 50 cm | 40 cm | 45 cm | 50 cm | 45 cm | 50 cm |
| Bar length (inch) | 16 in | 20 in | 16 in | 18 in | 20 in | 18 in | 20 in |
| Sprocket type | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
| Gauge | .050″ | .050″ | .058″ | .058″ | .050″ | .050″ | .050″ |
| Dimensions | |||||||
| Weight (excl. cutting equipment) | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs |
| Sound and noise | |||||||
| Sound pressure level at operators ear | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) |
| Sound power level, guaranteed (LWA) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
| Sound power level, measured | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) |
| Vibration | |||||||
| Equivalent vibration level (ahv, eq) rear handle | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² |
| Lubricant | |||||||
| Oil tank volume | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | |||||||
|
Exhaust emissions (CO₂ EU V)2
|
844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh |
