Description
| Engine |
16″ SN .325″ 1,3 mm SP33G
SKU: 967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
SKU: 967 69 09‑38
|
Chain speed at max power |
64.3 fts | 64.3 fts |
|---|---|---|
Cylinder displacement |
50.1 cm³ | 50.1 cm³ |
Output shaft power1 |
4 hp | 4 hp |
Torque, max. |
3.15 Nm | 3.15 Nm |
Torque, max. at rpm |
7,800 rpm | 7,800 rpm |
Clutch engagement speed (±120) |
3,900 rpm | 3,900 rpm |
Electrode gap |
0.02 in | 0.02 in |
Idling speed |
2,800 rpm | 2,800 rpm |
Ignition module air gap |
0.01 in | 0.01 in |
Maximum power speed |
10,200 rpm | 10,200 rpm |
Oil pump type |
Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
Spark Plug |
NGK CMR6H | NGK CMR6H |
| Equipment | ||
Recommended bar length, min |
13 in | 13 in |
Pitch |
.325″ | .325″ |
Recommended bar length, max |
20 in | 20 in |
Chain type |
SP33G | SP33G |
Bar length |
40 cm | 45 cm |
Bar length (inch) |
16 in | 18 in |
Sprocket type |
Rim 7 | Rim 7 |
Gauge |
.050″ | .050″ |
| Dimensions | ||
Weight (excl. cutting equipment) |
12.3 lbs | 12.3 lbs |
| Sound and noise | ||
Sound pressure level at operators ear |
107 dB(A) | 107 dB(A) |
Sound power level, guaranteed (LWA) |
117 dB(A) | 117 dB(A) |
Sound power level, measured |
115 dB(A) | 115 dB(A) |
| Vibration | ||
Equivalent vibration level (ahv, eq) rear handle |
4.6 m/s² | 4.6 m/s² |
Equivalent vibration level (ahv, eq) front handle |
4 m/s² | 4 m/s² |
| Lubricant | ||
Oil tank volume |
0.68 US pint | 0.68 US pint |
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | ||
Exhaust emissions (CO₂ EU V)2 |
813 g/kWh | 813 g/kWh |
