Description
| Engine |
18″ X-Tough RSN, C35 X-Cut (US/CA)
SKU: 967 69 08‑28
|
16″ SN .325″ 1,5 mm S35G
SKU: 967 69 08‑16
|
18″ SN .325″ 1,5 mm S35G
SKU: 967 69 08‑18
|
20″ SN .325″ 1,5 mm S35G
SKU: 967 69 08‑20
|
20″ X-Tough RSN, C35 X-Cut (US/CA)
SKU: 967 69 08‑30
|
16″ SN .325″ 1,3 mm SP33G
SKU: 967 69 08‑36
|
18″ SN .325″ 1,3 mm SP33G
SKU: 967 69 08‑38
|
18″ X-Tough RSN, C33 X-Cut (US/CA)
SKU: 967 69 08‑48
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 08‑50
|
20″ X-Tough RSN, C33 X-Cut (US/CA)
SKU: 967 69 08‑70
|
Chain speed at max power |
64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts |
|---|---|---|---|---|---|---|---|---|---|---|
Cylinder displacement |
50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ |
Output shaft power1 |
4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp |
Torque, max. |
3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm |
Torque, max. at rpm |
7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm |
Clutch engagement speed (±120) |
3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
Electrode gap |
0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
Idling speed |
2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
Ignition module air gap |
0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
Maximum power speed |
10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm |
Oil pump type |
Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
Spark Plug |
NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
| Equipment | ||||||||||
Recommended bar length, min |
13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
Pitch |
.325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ |
Recommended bar length, max |
20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in |
Chain type |
C33 | S35G | S35G | S35G | C35 | SP33G | SP33G | C35 | SP33G | C33 |
Bar length |
450 mm | 40 cm | 45 cm | 50 cm | 500 mm | 40 cm | 45 cm | 450 mm | 50 cm | 500 mm |
Bar length (inch) |
18 in | 16 in | 18 in | 20 in | 20 in | 16 in | 18 in | 18 in | 20 in | 20 in |
Sprocket type |
Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
Gauge |
.050″ | .058″ | .058″ | .058″ | 1 mm | .050″ | .050″ | 1 mm | .050″ | .050″ |
| Dimensions | ||||||||||
Weight (excl. cutting equipment) |
11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs |
| Sound and noise | ||||||||||
Sound pressure level at operators ear |
107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) |
Sound power level, guaranteed (LWA) |
117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) |
Sound power level, measured |
115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
