Description
| Engine |
18″ RSN 3/8″ 1,3 mm C83
SKU: 970 50 14‑04
|
18″ RSN 3/8″ 1,5 mm C85
SKU: 970 50 14‑05
|
20″ RSN 3/8″ 1,3 mm C83
SKU: 970 50 14‑06
|
20″ RSN 3/8″ 1,5 mm C85
SKU: 970 50 14‑07
|
24″ RSN 3/8″ 1,3 mm C83
SKU: 970 50 14‑08
|
24″ RSN 3/8″ 1,5 mm C85
SKU: 970 50 14‑09
|
Chain speed at max power |
69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts |
|---|---|---|---|---|---|---|
Cylinder displacement |
59.8 cm³ | 59.8 cm³ | 59.8 cm³ | 59.8 cm³ | 59.8 cm³ | 59.8 cm³ |
Output shaft power1 |
4.16 hp | 4.16 hp | 4.16 hp | 4.16 hp | 4.16 hp | 4.16 hp |
Torque, max. |
3.51 Nm | 3.51 Nm | 3.51 Nm | 3.51 Nm | 3.51 Nm | 3.51 Nm |
Torque, max. at rpm |
6,100 rpm | 6,100 rpm | 6,100 rpm | 6,100 rpm | 6,100 rpm | 6,100 rpm |
Clutch engagement speed (±120) |
4,300 rpm | 4,300 rpm | 4,300 rpm | 4,300 rpm | 4,300 rpm | 4,300 rpm |
Electrode gap |
0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
Idling speed |
2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
Ignition module air gap |
0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
Maximum power speed |
9,600 rpm | 9,600 rpm | 9,600 rpm | 9,600 rpm | 9,600 rpm | 9,600 rpm |
Oil pump type |
Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow |
Spark Plug |
NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
| Equipment | ||||||
Recommended bar length, min |
13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
Pitch |
3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ |
Recommended bar length, max |
24 in | 24 in | 24 in | 24 in | 24 in | 24 in |
Chain type |
C83 | C85 | C83 | C85 | C83 | C85 |
Bar length |
45 cm | 45 cm | 50 cm | 50 cm | 60 cm | 60 cm |
Bar length (inch) |
18 in | 18 in | 20 in | 20 in | 24 in | 24 in |
Gauge |
.050″ | .058″ | .050″ | .058″ | .050″ | .058″ |
| Dimensions | ||||||
Weight (excl. cutting equipment) |
13.01 lbs | 13.01 lbs | 13.01 lbs | 13.01 lbs | 13.01 lbs | 13.01 lbs |
| Sound and noise | ||||||
Sound pressure level at operators ear |
106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) |
Sound power level, guaranteed (LWA) |
115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
Sound power level, measured |
114 dB(A) | 114 dB(A) | 114 dB(A) | 114 dB(A) | 114 dB(A) | 114 dB(A) |
| Vibration |
