Description
Included
-
Nose type – Sprocket nose
-
Spikes – Mounted
-
Chain typ – SP21G
-
Bar length – 12/14/16 in
Not Included
-
Battery charger
-
Battery
| Engine |
Tophandle No battery / No Charger, Bluetooth
SKU: 970 64 68‑12
|
Tophandle No battery / No Charger, Bluetooth
SKU: 970 64 68‑14
|
Tophandle No battery / No Charger, Bluetooth
SKU: 970 64 68‑16
|
| Chain speed at max power | 79 fts | 79 fts | 79 fts |
|---|---|---|---|
| Battery voltage | 40 V | 40 V | 40 V |
| Battery type | Li-Ion | Li-Ion | Li-Ion |
| Motor type | BLDC (brushless) | BLDC (brushless) | BLDC (brushless) |
| Oil pump type | Adjustable flow | Adjustable flow | Adjustable flow |
| Equipment | |||
| Recommended bar length, min | 12 in | 12 in | 12 in |
| Pitch | .325″ mini | .325″ mini | .325″ mini |
| Recommended bar length, max | 16 in | 16 in | 16 in |
| Chain type | SP21G | SP21G | SP21G |
| Battery | Not included | Not included | Not included |
| Bar length | 30 cm | 35 cm | 40 cm |
| Bar length (inch) | 12 in | 14 in | 16 in |
| Sprocket type | Rim 7 | Rim 7 | Rim 7 |
| Gauge | .043″ | .043″ | .043″ |
| Dimensions | |||
| Weight (excl. battery and cutting equipment) | 6.39 lbs | 6.39 lbs | 6.39 lbs |
| Sound and noise | |||
| Sound pressure level at operators ear | 91 dB(A) | 91 dB(A) | 91 dB(A) |
| Sound power level, guaranteed (LWA) | 104 dB(A) | 104 dB(A) | 104 dB(A) |
| Sound power level, measured | 102 dB(A) | 102 dB(A) | 102 dB(A) |
| Vibration | |||
| Equivalent vibration level (ahv, eq) rear handle | 4.1 m/s² | 4.1 m/s² | 4.1 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 4.7 m/s² | 4.7 m/s² | 4.7 m/s² |
| Lubricant | |||
| Oil tank volume | 0.42 US pint | 0.42 US pint | 0.42 US pint |
