Description
| Engine |
20″ Bar, .3/8″ Pitch, .050″ Gauge
SKU: 965 96 83‑08
|
Power head
SKU: 965 96 83‑01
|
20″ Bar, .3/8″ Pitch, .058″ Gauge
SKU: 965 96 83‑09
|
24″ Bar, .3/8″ Pitch, .050″ Gauge
SKU: 965 96 83‑11
|
24″ Bar, .3/8″ Pitch, .058″ Gauge
SKU: 965 96 83‑12
|
28″ Bar, .3/8″ Pitch, .050″ Gauge
SKU: 965 96 83‑15
|
28″ Bar, .3/8 Pitch, .058″ Gauge
SKU: 965 96 83‑21
|
32″ RSN 3/8″ 1,6 mm H83
SKU: 965 96 83‑43
|
Chain speed at max power |
74.5 fts | 74.5 fts | 74.5 fts | 74.5 fts | 74.5 fts | 74.5 fts | 74.5 fts | 74.5 fts |
|---|---|---|---|---|---|---|---|---|
Cylinder displacement |
70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ |
Output shaft power1 |
5.5 hp | 5.5 hp | 5.5 hp | 5.5 hp | 5.5 hp | 5.5 hp | 5.5 hp | 5.5 hp |
Torque, max. |
3.8 Nm | 3.8 Nm | 3.8 Nm | 3.8 Nm | 3.8 Nm | 3.8 Nm | 3.8 Nm | 3.8 Nm |
Torque, max. at rpm |
6,600 rpm | 6,600 rpm | 6,600 rpm | 6,600 rpm | 6,600 rpm | 6,600 rpm | 6,600 rpm | 6,600 rpm |
Clutch engagement speed (±120) |
3,900 rpm | 3,600 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
Electrode gap |
0 in | 0.02 in | 0 in | 0 in | 0 in | 0 in | 0 in | 0 in |
Idling speed |
2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm |
Ignition module air gap |
0 in | 0 in | 0 in | 0 in | 0 in | 0 in | 0 in | 0 in |
Maximum power speed |
10,200 rpm | 9,600 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm |
Oil pump capacity, max |
20 ml/min | 21 ml/min | 20 ml/min | 20 ml/min | 20 ml/min | 20 ml/min | 20 ml/min | 20 ml/min |
Oil pump capacity, min |
4 ml/min | 4 ml/min | 4 ml/min | 4 ml/min | 4 ml/min | 4 ml/min | 4 ml/min | 4 ml/min |
Oil pump type |
Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic |
Spark Plug |
Champion RCJ7Y, NGK BPMR7A | NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A | Champion RCJ7Y, NGK BPMR7A |
| Equipment | ||||||||
Recommended bar length, min |
16 in | 15 in | 16 in | 16 in | 16 in | 16 in | 16 in | 16 in |
Pitch |
3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ | 3/8″ |
Recommended bar length, max |
28 in | 28 in | 28 in | 28 in | 28 in | 28 in | 28 in | 28 in |
Chain type |
H42 | — | H42 | H42 | H42 | H42 | H42 | H83 |
Bar length |
50 cm | 0 cm | 50 cm | 60 cm | 60 cm | 70 cm | 70 cm | 81 cm |
Bar length (inch) |
20 in | 0 in | 20 in | 24 in | 24 in | 28 in | 28 in | 32 in |
Sprocket type |
Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
Gauge |
.058″ | .058″ | .058″ | .058″ | .058″ | .058″ | .058″ | .063″ |
| Dimensions | ||||||||
Weight (excl. cutting equipment) |
14.6 lbs | 14.5 lbs | 14.6 lbs | 14.6 lbs | 14.6 lbs | 14.6 lbs | 14.6 lbs | 14.6 lbs |
| Sound and noise | ||||||||
Sound pressure level at operators ear |
110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) |
Sound power level, guaranteed (LWA) |
119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) |
Sound power level, measured |
118 dB(A) | 118 dB(A) | 118 dB(A) | 118 dB(A) | 118 dB(A) | 118 dB(A) | 118 dB(A) | 118 dB(A) |
| Vibration | ||||||||
Equivalent vibration level (ahv, eq) rear handle |
8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² |
Equivalent vibration level (ahv, eq) front handle |
5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² |
| Lubricant | ||||||||
Oil tank volume |
0.89 US pint | 0.89 US pint | 0.89 US pint | 0.89 US pint | 0.89 US pint | 0.89 US pint | 0.89 US pint | 0.89 US pint |
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | ||||||||
Exhaust emissions (CO₂ EU V)2 |
742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh |
