Description
| Engine |
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑02
|
16″ SN .325″ 1,5 mm S35G
SKU: 967 69 06‑16
|
18″ SN .325″ 1,5 mm S35G
SKU: 967 69 06‑18
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑28
|
16″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑36
|
18″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑38
|
20″ SN .325″ 1,3 mm SP33G
SKU: 967 69 06‑40
|
Chain speed at max power |
62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts |
|---|---|---|---|---|---|---|---|
Cylinder displacement |
50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ |
Output shaft power1 |
3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp |
Torque, max. |
2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm |
Torque, max. at rpm |
7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm |
Clutch engagement speed (±120) |
3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
Electrode gap |
0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
Idling speed |
2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
Ignition module air gap |
0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
Maximum power speed |
9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm |
Oil pump type |
Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
Spark Plug |
NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
| Equipment | |||||||
Recommended bar length, min |
13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
Pitch |
.325″ | .325″ | .325″ | .325″ | .325″ | .325″ | .325″ |
Recommended bar length, max |
20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in |
Chain type |
SP33G | S35G | S35G | SP33G | SP33G | SP33G | SP33G |
Bar length |
50 cm | 40 cm | 45 cm | 50 cm | 40 cm | 45 cm | 50 cm |
Bar length (inch) |
20 in | 16 in | 18 in | 20 in | 16 in | 18 in | 20 in |
Sprocket type |
Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
Gauge |
.050″ | .058″ | .058″ | .050″ | .050″ | .050″ | .050″ |
| Dimensions | |||||||
Weight (excl. cutting equipment) |
11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs |
| Sound and noise | |||||||
Sound pressure level at operators ear |
106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) |
Sound power level, guaranteed (LWA) |
115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
Sound power level, measured |
113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) |
| Vibration | |||||||
Equivalent vibration level (ahv, eq) rear handle |
4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² |
Equivalent vibration level (ahv, eq) front handle |
4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² |
| Lubricant | |||||||
Oil tank volume |
0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint |
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | |||||||
Exhaust emissions (CO₂ EU V)2 |
844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh |
