Sterling

Sterling Atlas 1/2″ Rigging Rope- No splice

$304.99

1/2″ arbor rigging line is the go-to rope for everyday rigging with a tightly braided sheath that protects the core without sacrificing handling.



This 1/2″ (13mm) Atlas double braid rigging line is the workhorse of the Sterling arbor rigging lines. Sterling redesigned this double-braid construction with a polyester sheath and nylon core construction that provides a huge increase in overall strength, while lowering the static elongation. Atlas resists picking and protects the nylon core without sacrificing handling due to a tightly woven polyester sheath. The Atlas double braid rigging line works great with a capstan winch, port a wrap, or rigging blocks.

Requesting Brochure for...

6057Sterling Atlas 1/2″ Rigging Rope- No splice

Address
SKU: ATLAS12-NG-200-NS Categories: , Tags: , , , Brand:

    Description

    The ½” Atlas rigging line is the thinnest diameter in Sterling’s series of arbor rigging lines, ideal for lighter-duty dynamic rigging. Like the 9/16” and 5/8” the ½” version has a redesigned double-braid construction that provides a huge increase in overall strength. The new core construction has lowered the static elongation but still allows rope to absorb energy/impact force and can limit peak forces when catching wood in negative rigging applications. The tightly woven polyester sheath resists picking, and protects the core without sacrificing handling and flexibility. The ½”, along with the other diameters in the Atlas series are ideal for use in a Port-a-Wrap, capstan winch or rigging blocks.

    Nylon core/polyester cover construction

    – Unmatched strength-to-weight ratio

    – Over 32% stronger than the previous Atlas design rigging rope

    – Sturdy double-braid construction

    Added eyes by Rope Logic include Scannable compatibility for track and trace capability.

    Additional information

    Weight 18.5 lbs
    Dimensions 13 × 13 × 7.5 in
    Elongation

    Elongation at 10% MBS: 4.1%, Elongation at 300lbs: 0.9%

    Diameter

    13mm (1/2")

    Rope Length

    200 ft

    Material

    Nylon/Polyester

    Strand Count

    32 Strand

    Tensile Strength

    10,800 lbs (48 kN)

    Average Breaking Strength

    11,500lbs

    Sheath Percentage

    49%
